● AC/DC type coil specifications,16A contact switching capability
● Low height: only 15.7mm
● The medium voltage between the coil and the contact is 5KV
● Creepage distance is 10mm
● Dust-proof and flux-proof types are available
● Equipped with a variety of outlets to choose from
● Appearance size: 29×12.7×15.7mm
详细参数
| 产品型号 | JA115F2 | |
| 绝缘电阻 | 100mΩ(500VDC) | |
| 介质耐压 | 线圈与触点间 | 5000VAC 1min |
| 断开的触点间 | 1000VAC 1min | |
| 动作时间 | 额定电压 | ≤15ms |
| 释放时间 | 额定电压 | ≤8ms |
| 冲击 | 稳定性 | 10G |
| 强度 | 100G | |
| 振动 | 10-55Hz,1.5mm | |
| 湿度 | 5%~85% | |
| 温度范围 | -40℃~85℃ | |
| 最大转换频率 | 电气寿命：1200次/小时 机械寿命：18000次/小时 | |
| 触点形式 | 1A,1B,1C | |
| 接触电阻 | ≤100mΩ | |
| 负 载 | 阻性负载(COSΦ=1) | |
| 触点材料 | 银合金 | |
| 触点负载 | 16A/250VAC 16A/30VDC | |
| 最小负载 | 100mA 5VDC | |
| 最大切换电流 | 16A | |
| 最大切换功率 | 4000VA/480W | |
| 最大切换电压 | 250VAC/30VDC | |
| 机械耐久性 | 1x107次(at 300次/分钟) | |
| 电耐久性 | 1x105次 (at 300次/分钟) | |
